Type of Tooling: “B” “D” “4”D” +4”B””
No. of Station: 8 Station / 10 Station
Tablets Output /hour* (Max.): 18000
Operating Pressure Max. (Ton): 6
Tablet Diameter Max. (mm): 16 and 25
Turret RPM Max. ( Max.): 30
Approx Price:
Single Rotary Mini Tablet Press Machine
₹450,000.00
Get Latest Price
Category: Tablet Press Machine
Get Quote
Request Call Back
| TECHNICAL SPECIFICATIONS | ||
| Model | JSK – 8 Stations | JSK– 12 Stations |
| Type Of Tooling | Special | Special |
| Number of Station | 8 | 12 |
| Tablets Output /hour* (Max.) | 10560 | 10560 |
| Operating Pressure Max. (Ton) | 12 | 12 |
| Tablet Diameter Max. (mm) | 40 | 40 |
| Depth of Fill (mm) | 30 | 30 |
| Turret RPM Max. | 22 | 22 |
| Upper Punch Penetration (mm) | 1.5-8 | |
| Total Ele. Power (hp) | 5 HP | |
| Electric Power Supply | 930 RPM, 3 PH, 415 V, 50 Hz OR As Per the requirement of Customer | |
| Tablet Press Dimension (mm)(Approx.) | 980 x 1020 x 1820 | |
| Net Weight (kgs) (Approx.)) | 1000 | |
The Single Rotary Mini Tablet Press / Compression Machine is designed with strict adherence to GMP standards. It features a durable construction with a single-sided turret made from high-quality iron casting.
This machine is ideal for both research and development (R&D) and small-scale production needs. It’s especially beneficial when dealing with high-value ingredients in tablet formulations, commonly referred to as a lab tablet press or compression machine.
Key Features of the Single Rotary Mini Tablet Press / Compression Machine:
- Pre-compression as Standard: Comes equipped with a pre-compression facility as a default feature.
- Variable Drive System: Includes an A.C. variable drive and a fixed pulley, powered by a central pillar using a worm reduction gearbox.
- Protective Guards: Lower guards are made of stainless steel, while the upper guards are transparent acrylic, allowing for easy observation of the tablet compression process.
- Electronic Tablet Counting System: Ensures accurate counting during production.
- Efficient Granule Feeding: Granules are delivered via an open feed frame, minimizing material wastage and ensuring smooth operation.
- Optional Force-Feeding Attachment: Available for compressing challenging, fluffy, or fine granules.
- Compact and Mobile: Table-top design that is easy to move and clean.
- User-Friendly Controls: External controls for pre-compression adjustment, tablet thickness, and turret speed provide ease of operation.
